Short Circuits

What is a short circuit, how does a short circuit manifest and what are the consequences?


A short circuit (sometimes abbreviated to short or s/c) is an electrical ‘sub’ or ‘child’ circuit that abnormally evolves and allows an electrical current to flow along an unintended pathway.


Generally a short circuit will have a very low electrical impedance (resistance). The manifestation of a short circuit, results in excessive current flowing through the circuit which can provoke damage to the parent electrical circuit, overheating, fire or explosion.



Although usually the result of an electrical ‘fault’, there are cases where short circuits are intentionally introduced, for example in the case of voltage-sensing crowbar circuit protectors.


An example of a short circuit occurs when the positive and negative terminals of a battery are connected with a low-resistance conductor, like a wire. With a low resistance in the connection, a high current will flow, causing the delivery of a large amount of energy in a short period of time.



In electrical devices, unintentional short circuits are usually caused when the outer insulation of a cable or wire insulation deteriorates/breaks down or conductive debris or moisture (water) is introduced, allowing electrical current to flow along a different path than that intended.



Given the manifestation of a short circuit and the consequential increase in flow of electrical current, the circumstance will quickly trigger an overcurrent protection device, say a fuse or miniature circuit breaker (MCB).


A short circuit may lead to formation of an electric arc. This being a volume of hot gas referred to as a ‘plasma’. An electric arc is highly electrically conductive and can persist even after significant amounts of original conductor material (referred to as electrodes) has evaporated.


Surface erosion of conductors/electrodes is a typical sign of electric arc damage. Even physically short arcs can remove significant amounts of material from the electrodes. The temperature of the resulting electrical arc is very high (tens of thousands of degrees), causing the metal on the contact surfaces to melt, pool and migrate with the current, as well as to escape into the air as fine particulate matter.
